Inline Duct Explosion Valve

The explosion duct valve is used in order to prevent an explosion in the plant being channelled back to the production premises and machines. The explosion duct valve is mounted on the duct section between the plant and the dust source.

This is an enquiry only product.

Additional Information

Explosion Duct Valves are mounted in the duct run between the plant and the dust source.

An explosion valve will stop explosions that occur in BOTH FLOW DIRECTIONS of the normal flow.

The valve can be mounted on either the inlet side or outlet side of a dust seperator.

Tested and Approved to :

Dust Explosion Class St. 1
EN 16447:2014 - Explosion insulation systems
EN 14460: 2018 - Explosion resistant equipment
EN 1127-1: 2019 - Explosion preventiobn and protection - Part 1
2014/34/EU ATEX regulations Certifications
ISO9001: 2015 Quality Management

Call 0508 69 38 28 for more information.
